High Capacity--Coal Bagging Machine Net weighing machine 10bags per minute, Dual hopper Coal Bagger; Charcoal Bagger ;25kg Bagging Machine
Industrial Bagging Machine Suitable Materials:
Coal,Nature Charcoal(With 3-6cm), Briquettes, Pebble,Gravel etc.
Support kraft bags, paper bags, woven bags,pp bags all of open mouth bags
Weigher Packing Machine Technical Parameters:
Precision | :+/- 2-3 material weight |
Packing speed | : 500-650bags per hour |
Weighing scale | :10-50kg per bag |
Power Supply | : 220-240Va.c and 4N-380-415Va.c,50Hz/60Hz |
Power Dissipation | : 4.5kW |
Compressed Air | : 0.4MPa~0.6MPa |
Compressed Air Consume | : 0.6m3 per hour |
Feed-in system | : inclined Multi-stage Belt Feeder |
Semi-automatic Weighing Filling Machine Advantage:
1. Use Mettler-Toledo Brand Load Cell
2. Use France Schneider Brand electric parts
3. Use Taiwai Airtac or Japanese CKD/SMC or Germany FESTO brand pneumatic parts
4. Ensure whole machine life online after sales service
5. Mechnical usage design period >10 years
6. Weighing controller usage design period >15 years
7. 25 years experiences in industrial weighing scale
8. Domesitc over 600 sets usage record and exported this type to Europe, Asia, South Africa 10 countries
Belt Feeder Weighing Machine Main Structures:
1. Auto dosing fill system (multi-speed inclined belt feeder)
2. Auto weighing balance(Dual hopper weigher)
3. Auto belt conveyor
4. Sewing machine or Heat sealing machine
5. Electric control cabinet
Charcoal Bagging Machine Flowing Process:
Auto feeding(fast/middle/fine)-->Auto dosing and weighting(two hoppers)-->Manual bag placing-->Auto filling into bags and release the bags on conveyor-->Auto bag sewed or sealed-->next round
