    Product Details:

    Place of Origin: China
    Brand Name: RL
    Certification: CE
    Model Number: DCS-30 SP

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Set/Sets
    Price: negotiation
    Packaging Details: Standard Export Wooden Case
    Delivery Time: 20 working days after received your payment
    Payment Terms: L/C,T/T
    Supply Ability: 20 Set/Sets per Month
    Contact Now
    Detailed Product Description
    Dimension(LWH/cm): L2500 W1850 H2100 Application: Food Industry
    Bag Size(mm): Customized Voltage: 220V-380V
    Packaging Speed: 150~250 Bags/hour Power: 2.5KW
    Standard: CE Automatic Grade: Semi-Automatic

    200bags / hour Potato Packing Machine ,  Potato / Garic / Carrot / Apple Bagger , Garic Packing Scale /  Bagger





    Suitable Material:

    potato, onion,garlic,apple etc.



    Technical parameter
    Type DCS-30 SP A

    Power consumption

     2.5 KW

    Air gas consumption

    0.3M3/hour

    Request compressed air

    >=0.4Mpa
    Power Supply

    AC380V / 220V 50 -60 HZ

    Machine size

     2500 * 1850 * 2100(mm)

    Package Weight and capacity

    2-10kg or 5-30kg ;150-250bags/hour





    Our Advantage:



    1. Use multi-stage inclined belt feeder,combine inveter to adjust all necessary motor speed.

    2. Ensure whole machine life after online sales service .

    3. We ourselves file the programme of weighing controller, ensure most easlist operation and setting parameters.

    4. Gross weighing type





    Main Function:

    Automatic filling system and dosing weighing balance

    Automatic conveyor belt transportation

    Automatic sewing or heat sealing machine(based on bag types)

    Electric control cabinet and weighing controller



    Main operation:

    Manual place the bags into clamp bar-->Automatic filling and dosing-->Automatic bag discharge-->Automatic belt conveyor transportation-->Bag sewed or sealed-->Next Round
